3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling

3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling
3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling

Большие изображения :  3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling

Подробная информация о продукте:
Место происхождения: ХУНАН, Китай
Фирменное наименование: SOLLROC
Оплата и доставка Условия:
Количество мин заказа: 1
Цена: $1,000

3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling

описание
Масса: 29 кг Материал: Стержневая сталь
Размер молотка: 3 дюйма Нить: 3 '' Remet
Внешний диаметр: 81mm Длина: 1069 мм
Диапазон отверстий: 84-105 мм Давление воздуха: Высокое давление воздуха
Рабочее давление: 10,5-3,5 МПа Частота воздействия: 30 Гц при 2,4 МПа
Скорость вращения: 25-40 р/мин Потребление воздуха: 7-14 мграни/мин
Сдержал хвостовик: SRC531 Поток соединения: 3 '' Remet
Тип машины: Буровой инструмент
Выделить:

3 inch Down The Hole Hammer

,

1069mm Length Down The Hole Hammer

,

81mm External Diameter Down The Hole Hammer

High Air Pressure SRC531 RC Reverse Circulation Hammer
Company Introduction
  • Our factory has specialized in manufacturing drilling tools and spare parts for over 10 years
  • We utilize advanced technology and equipment
  • Our technicians have more than 13 years of professional experience
Product Introduction

Reverse circulation drilling efficiently collects uncontaminated samples by transporting them through a hollow pipe system. This method prevents sample contamination from surface materials, ensuring accurate geological analysis.

Technical Specifications
Length (less bit) Weight (less bit) External Diameter Bit Shank Hole Range Connection Thread
1069mm 29.0kg 81mm SRC531 84-100 3''Remet
Working Pressure Impact Rate at 2.4Mpa Recommended Rotation Speed Air Consumption
1.5-3.5Mpa 30HZ 25-40r/min 1.7Mpa: 7 m³/min 2.4Mpa: 10 m³/min 3.0Mpa: 14 m³/min
Product Advantages
  • Reduces overall drilling costs by up to 40% compared to conventional methods
  • Delivers faster results with quick completion of drilling process
  • Safe operation requiring fewer man hours
  • Lower water consumption than other mining methods
  • Simple and easy operation
  • Efficient sample organization with depth and location tracking for precise mineral deposit identification
3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 0 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 1
Delivery & Packaging

Available shipping methods: By sea, by air, or by express

3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 2 3 inch Down The Hole Hammer with 1069mm Length and 81mm External Diameter for Efficient Drilling 3
Packaging Options
  • Plywood cases
  • Plywood cases with pallet
